Ball valve QS-4mm QH-QS-4
product description
Ball valve QS-4mm QH-QS-4
| Pneumatic connection, port 1 | QS-4 |
| Pneumatic connection, port 2 | QS-4 |
| Nominal size | 2,5 mm |
| Operating pressure | -1 ... 10 bar |
| Ambient temperature | 0 ... 60 °C |
| Operating medium | Operating medium Compressed air in accordance with ISO8573-1:2010 [7:-:-]-] |
| Design structure | Ball valve |
| Note on operating and pilot medium | Lubricated operation possible (subsequently required for further operation) |
| Product weight | 12 g |
