Following the success of the Predator Jet, Pilot-RC sets a new benchmark in the sport and 3D jet segment with the Matrix.

The Matrix was designed from the ground up as a high-performance sport jet with full 3D capability. Based on intensive aerodynamic testing and the experience gained from the Predator, an aircraft was created that combines maximum precision, agility, and stability. Through close collaboration with one of the world’s leading jet pilots, the flight characteristics were optimized down to the smallest detail.

The Result

• Direct control feel with precise feedback in all flight attitudes

• Outstanding roll rates and neutral knife-edge characteristics

• Optimized airflow for clean and precise aerobatic maneuvers

• Maximum 3D performance, including extreme slow-flight and post-stall maneuvers

• A balanced airframe that excels in both precision F3S aerobatics and aggressive 3D flying

Designed by Mirco Pecorari (Aircraft Studio Design), the Matrix combines technical efficiency with a dynamic design language inspired by modern supercars. Every contour is aerodynamically optimized for minimal drag, maximum control, and a distinctive appearance.

The Pilot-RC Matrix is more than just a sport jet – it is a tool for pilots who demand the highest level of precision and dynamic performance.

Specifications

Pilot-RC Matrix – Features & Specifications

✈️ Key Features

• Extremely lightweight full composite construction, specifically designed for precise sport flying and uncompromising 3D performance

• Out-of-mold painted finish, resulting in no visible seam lines

• Optimized turbine access for quick installation and removal

• Tool-free field setup thanks to quick-release wing mounts

• Easy horizontal stabilizer installation using a single top clamp (only a few turns required)

• Removable wings and tail surfaces for easy transport

• Integrated equipment board for a clean and organized electronics installation – wiring can largely be hidden

• Pre-installed cable ducts for elevator and rudder servo extensions

📦 Package Includes (Hardware Included)

• Complete airframe (including carbon wing tubes and pre-installed painted fiberglass control horns)

• Electric retract landing gear

• Servo extensions

• Vector thrust tube

• 3,800 ml fuel bag

• Pre-assembled linkages with ball joints

• Servo connector brackets

⚙️ Required Hardware

(Not included)

Turbine

• 100–140 N → recommended for normal sport flying

• 160–180 N → for 3D vector flight

⚠️ Note: High-speed or high-G flying is not recommended in this configuration.

Servos

Total: 10 servos (3 standard size + 7 medium size)

3 High-Torque Standard Servos

• 2 for flaps (minimum 40 kg)

• 1 for rudder (minimum 40 kg)

7 Medium Size Servos

(Size: 35 × 15 × 30 mm)

• 2 for ailerons (minimum 16 kg)

• 2 for elevators (minimum 16 kg)

• 1 for vector elevator (minimum 16 kg) – optional

• 1 for vector rudder (minimum 16 kg) – optional

• 1 for nose wheel steering (minimum 10 kg)

Additional Required Components

• Transmitter and receiver

• Batteries

• Powerbox

• Various standard RC accessories
